Industrial Screw Air Compressors With VFD in Kolkata

ISO 9001:2015 TUV certified and serving industries across Pan India since 2003.

View All Products
0

Years Experience

0

Happy Clients

0

Countries Served

Energy Efficient VFD Screw Air Compressors in Kolkata

Industries in Kolkata face rising power costs, fluctuating air demand, and frequent load changes across daily production cycles. Fixed speed compressors waste energy during partial load operation and struggle to match real time air demand. This leads to higher electricity bills, pressure instability, and avoidable wear on components.

Frank Compressors manufactures VFD screw air compressors under ISO 9001 certified quality systems. Our variable frequency drive technology adjusts motor speed based on actual air demand. This ensures stable pressure, reduced energy use, and longer equipment life for continuous industrial operations across Kolkata and West Bengal.

Why Kolkata Industries
Choose VFD Screw
Air Compressors

Kolkata industries operate with varying air demand across shifts, machines, and processes. A VFD screw air compressor responds instantly to these changes and keeps production stable and efficient.

Call Now

Energy Savings During Partial Load Operation

VFD screw air compressors match air output to actual demand. This reduces power consumption during low load periods and cuts electricity costs significantly.

Stable Pressure for Sensitive Processes

The variable speed drive maintains constant pressure without spikes or drops. This protects tools, improves product quality, and reduces air leakage.

Reduced Mechanical Stress

Soft start and controlled speed changes reduce stress on motors and screw air ends. This extends service life and lowers maintenance frequency.

Key Features of Frank VFD Screw Air Compressors

  • The low RPM heavy duty screw air end delivers higher efficiency with low noise and strong energy savings.
  • he microprocessor based control system with a touchscreen shows all operating conditions and maintenance schedules for reliable performance.
  • Large oil filters and advanced air oil separators keep oil carryover below 3 PPM and extend service intervals.
  • The compressor meets low noise standards as per PN8NTC 2.3 measured at one meter distance in free field conditions.
  • A larger air and oil cooler with a high capacity cooling fan maintains low outlet air temperature.
  • The design supports tough environmental conditions and provides ample internal space for easy maintenance access.
  • Fewer moving components improve reliability and reduce mechanical wear.
  • Energy savings over three years exceed the initial equipment investment.
  • Trusted branded inverters from globally recognized manufacturers ensure stable and efficient operation.

Available Capacities for VFD Screw Air Compressors in Kolkata

Frank Compressors supplies a full range of VFD screw air compressors with installation and commissioning support across Kolkata and West Bengal.

7.5 HP VFD Screw Air Compressor
10 HP VFD Screw Air Compressor
15 HP VFD Screw Air Compressor
20 HP VFD Screw Air Compressor
25 HP VFD Screw Air Compressor
30 HP VFD Screw Air Compressor
40 HP VFD Screw Air Compressor
50 HP VFD Screw Air Compressor
60 HP VFD Screw Air Compressor
75 HP VFD Screw Air Compressor
100 HP VFD Screw Air Compressor
125 HP VFD Screw Air Compressor
Custom capacity models on request

Enquiry For Compressor

0

Happy Clients

0

Dealers

Screw Air Compressor With VFD Process

01

Air Intake

The compressor draws clean air through a high efficiency inlet filter.

02

Low RPM Compression

Twin screw rotors compress air smoothly with low noise and high efficiency.

03

VFD Control

The VFD adjusts motor speed to match air demand and save energy.

04

Oil Injection

Oil seals, cools, and lubricates the compression chamber.

05

Air Oil Separation

The separator removes oil and keeps carryover below 3 PPM

06

Air Cooling

The aftercooler reduces outlet air temperature.

07

Air Delivery

The system supplies stable compressed air at constant pressure.

Technical Specifications


Model		 Max Working
Pressure
in kg/cm2 		Motor
Flow cfm
Noise dB (A)
Weight (kgs)
L W H (mm)
HP Kw
Mute HD-15 7-10-13 15 11 71-60-48 72 365 950 x 770 x 1120
Mute HD-20 7-10-13 20 15 96-89-78 72 430
Mute HD-30 7-10-13 30 22 138-116-94 72 445
Mute HD-40 7-10-13 40 30 205-173-140 72 780
Mute HD-50 7-10-13 50 37.5 255-209-180 72 790 1310x1250x1430
Mute HD-75 7-10-13 75 55 368-303-271 73 1540
Mute HD-100 7-10-13 100 75 478-410-370 73 1540 1600x1524x1863
Mute HD-125 7-10-13 125 90 572-486-440 74 2480 1600x1524x1863
Base Mounted Screw Compressor (High Pressure Mute Series)
Mute HD-15 16 15 11 46 70 375 989x815x1125
Mute HD-20 16 20 15 57 70 440 1039x920x1245
Mute HD-25 16 25 18.5 78 70 455 1039x920x1245
Mute HD-30 16 30 22 92 70 496 1039x920x1245
Sectors

Industries Using VFD Screw Air Compressors in Kolkata

Heavy Engineering & Fabrication

Fabrication units and rolling mills use VFD screw air compressors to handle fluctuating air demand across cutting, blasting, and tool operations.

Pharma & Life Sciences

Pharma plants require precise pressure control for filling, coating, and packaging lines. VFD screw air compressors deliver stable airflow with high efficiency.

Food & Beverage Processing

Food processors benefit from energy savings during batch operations and varying production loads.

Textile & Jute Mills

Variable speed compressors support spinning and weaving machines that operate at changing loads across shifts.

Automobile & Auto Components

Assembly lines, spray booths, and pneumatic tools require constant pressure with minimal energy waste.

Warehousing & Cold Storage

Cold chain facilities use VFD screw air compressors to manage demand changes while operating in high humidity conditions.

Infrastructure & Metro Projects

Construction sites benefit from flexible air supply and reduced fuel and power costs.

Advantages Over Conventional Screw Compressors

Feature Standard Screw Air Compressor VFD Screw Air Compressor
How It Operates Runs at full speed and cycles on/off to meet demand Adjusts motor speed to match air demand
Energy Efficiency Uses more energy, especially under varying loads Saves energy by matching power output to need
Electricity Cost Higher over time for most operations Lower due to variable speed control
Startup Stress Constant start/stop puts stress on electrical and mechanical parts Smooth ramp up and down reduces wear
Air Delivery Delivers consistent output even at low demand Delivers only what is needed, reducing waste
Initial Cost Lower initial price Higher upfront investment
Maintenance Needs Simpler design may cost less to maintain VFD adds complexity and slightly higher service cost
Best Use Case Stable air demand with little change Fluctuating air demand with peaks and valleys
Operational Noise May run louder due to full speed cycles Runs quieter because it slows when demand drops
Control System Basic controls Advanced control for speed and output
Life of Equipment Average when used in heavy cycling Longer life thanks to smoother operation
Return on Investment (ROI) Longer payback in many settings Faster payback through energy savings
Power Factor Less optimized Better power factor improves electrical efficiency

Smart Controls for Energy Efficient Operations

Every Frank VFD screw air compressor includes an advanced digital control system.

  • Live display of pressure, temperature, power usage, and running hours
  • Automatic fault detection with early warning alerts
  • Energy consumption tracking for cost analysis
  • Maintenance reminders based on actual operating hours
  • Multi compressor sequencing for up to eight units
  • RS 485 connectivity for SCADA and centralized monitoring
  • Data logging for performance and efficiency reporting

These controls help Kolkata industries reduce downtime, plan maintenance, and maximize energy savings.

Why frank?

Why Choose Frank for VFD Screw Air Compressors in Kolkata?

ISO 9001 Certified Manufacturing

Each compressor undergoes strict quality checks before dispatch to ensure reliable industrial performance.

Complete Product Range

We offer oil injected, oil free, VFD, PM motor, and jumbo series compressors under one roof for total system compatibility.

Local Installation and Service Support

Our service team provides installation, commissioning, and after sales support across Kolkata and West Bengal with quick spare parts availability.

Upgrade to Energy Efficient VFD Screw Air Compressors

Share your air demand, operating pressure, shift pattern, and industry type. Our engineers will recommend the right VFD screw air compressor for your Kolkata facility with factory direct pricing and full technical support.

Call Whatsapp
FAQ

FAQs on VFD Screw Air Compressors in Kolkata

It uses a variable frequency drive to adjust motor speed based on actual air demand for energy efficient operation.

Depending on load variation, energy savings can reach up to thirty percent compared to fixed speed compressors.

Yes. These compressors are designed for continuous duty with efficient cooling and stable pressure control.

No. Air quality remains consistent due to efficient separation and cooling systems.

Yes. Features like effective cooling, humidity handling, and optional IP55 motors support local conditions well.

Yes. Frank Compressors offers installation, service, and genuine spare parts support across Kolkata and West Bengal.
