Heavy-Duty Oil Free Screw Compressors in Kolkata

Kolkata’s pharma plants, food processors, textile mills, electronics manufacturers, and hospitals cannot risk oil contamination anywhere in the compressed air line. Even minor oil carryover affects product quality, damages sensitive equipment, and creates compliance issues in GMP, ISO 8573, and food-grade production environments.

Frank Compressors manufactures oil free screw air compressors in Coimbatore and supplies directly across Kolkata and West Bengal in capacities from 10 HP to 75 HP. These two-stage VSD compressors use specialised rotor coatings for oil-free compression, operate between 57 dB and 67 dB, and deliver stable output across 7 bar, 8.5 bar, and 10 bar pressure settings with lower energy consumption and reduced operating cost.

Why Kolkata Industries
Choose Oil Free
Screw Air Compressors

Pharma units, food processing plants, textile mills, hospitals, and electronics manufacturers across Kolkata need compressed air that remains completely free from oil contamination during production. Oil-injected systems still carry downstream contamination risk, while oil free screw compressors remove that problem directly at the compression stage.

Call Now

Zero Oil in the Compression Chamber

Specially treated rotors compress air without oil contact, keeping compressed air free from oil vapour and contamination risk.

VSD Technology for Lower Power Consumption

Variable speed drive adjusts motor speed according to air demand, reducing electricity usage during lower production loads.

Low Noise for Production Environments

Operating noise between 57 dB and 67 dB suits cleanrooms, textile floors, hospitals, and indoor process facilities.

Two-Stage Compression Efficiency

Progressive two-stage compression produces cooler compressed air with higher volumetric efficiency than single-stage compressor systems.

Features of Frank Compressors Oil Free Screw Air Compressors

  • Two-stage compression for higher efficiency and lower outlet temperature
  • Specialised rotor coating and surface treatment for oil-free operation without lubrication
  • Variable speed drive (VSD) to match motor speed with actual air demand
  • Advanced control system that monitors and adjusts operating parameters automatically
  • Noise levels from 57 dB to 67 dB across the full model range
  • Available from 10 HP to 75 HP in nine standard configurations
  • Pressure output across three settings: 7 bar, 8.5 bar, and 10 bar
  • Sound enclosures and vibration isolators for reduced noise on the production floor
  • Pipe connections from 3/4 inch to 2 inch depending on model capacity
  • Lubrication oil volume from 20 to 80 litres across the model range
  • Compact skid-mounted base for straightforward installation in limited floor spaces
  • Meets stringent environmental and air quality standards for sensitive industrial applications

Enquiry For Compressor

0

Happy Clients

0

Dealers

How an Oil Free Screw Air Compressor Works?

01

Oil-Free Delivery

Specialised rotor coatings allow compression without oil entering the compressed air stream at any stage.

02

Air Intake

Inlet filter removes dust and particulates before air enters the first-stage compression chamber.

03

First Stage Compression

Male and female rotors compress incoming air progressively as cavity volume reduces toward the discharge port.

04

Intercooling

Intercooler lowers air temperature before second-stage compression to improve efficiency and reduce operating load.

05

Second Stage Compression

Pre-compressed air enters the second stage where pressure increases to the required outlet level.

06

Pressure Control & Delivery

VSD controller adjusts motor speed continuously to maintain stable outlet pressure during operation.

Two Stage Compressors For Engine

Models Motor Power
(HP)		 Pressure
(CFM/Bar)		 Lubrication
(L)		 Pipe Diameter
(inch)		 Noise
(db)		 Measure
L*W*H
(MM)		 Weight
(Kgs)
OFS - 10/7 Base
OFS - 10/8.5 Base
OFS - 10/7 Base		 10 42/7
38/8.5
31/10		 20 3/4" 57 1100×750×1350 430
OFS - 15/7 Base
OFS - 15/8.5/Base
OFS - 15/10/Base		 15 56/7
53/8.5
31/10		 20 3/4" 57 1100×750×1350 450
OFS - 20/7 Base
OFS - 20/8.5/Base
OFS - 20/10/Base		 20 84/7
77/8.5
70/10		 25 1" 57 1400×820×1500 570
OFS - 25/7 Base
OFS - 25/8.5/Base
OFS - 25/10/Base		 25 109/7
99/8.5
88/10		 30 1" 58 1400×820×1500 620
OFS - 30/7 Base
OFS - 30/8.5/Base
OFS - 30/10/Base		 30 130/7
120/8.5
106/10		 30 1" 60 1400×820×1500 640
OFS - 40/7 Base
OFS - 40/8.5/Base
OFS - 40/10/Base		 40 184/7
166/8.5
152/10		 40 1 1/2" 61 1690×1000×1600 980
OFS - 50/7 Base
OFS - 50/8.5/Base
OFS - 50/10/Base		 50 215/7
198/8.5
177/10		 60 1 1/2" 61 169×1000×1600 1010
OFS - 60/7/Base
OFS - 60/8.5/Base
OFS - 60/10/Base		 60 265/7
240/8.5
212/10		 60 1 1/2" 65 2050×1200×1500 1110
OFS - 75/7/Base
OFS - 75/8.5/Base
OFS - 75/10/Base		 75 354/7
318/8.5
276/10		 80 2" 67 2050×1200×1500 1200
Sectors

Industries We Supply Oil Free Screw Air Compressors in Kolkata

Pharmaceutical Manufacturing

Pharma plants rely on oil-free compressed air for sterile filling, tablet coating, and cleanroom pressurization systems.

Laser Cutting Facilities

Laser cutting operations use oil-free compressed air to protect cut quality and prevent lens contamination.

Food & Beverage Processing

Packaging, bottling and pneumatic conveying systems require oil-free compressed air for hygiene compliance.

Textile Production

Oil contamination may compromise quality of the fabric during weaving and yarn processing, thus textile mills use clean compressed air.

Electronics & Semiconductor Units

Precision electronics manufacturing requires contaminant-free compressed air to avoid defects in components and surfaces.

Printing & Packaging

Oil-free compressed air is used in the printing operation to prevent oil smudges during press and finishing.

Automotive Paint & Coating

Spray booths require oil-free compressed air to avoid fish-eye defects and coating failures.

Hospitals & Medical Facilities

For ventilators and surgical instruments, compressed air must be supplied cleanly and stably.

Control System & Operational Features

Frank oil free screw air compressors use an advanced control system built to manage all operating parameters without constant manual input.

  • VSD controller adjusts motor speed continuously based on real-time air demand
  • Automatic monitoring of pressure, temperature, and load at all operating conditions
  • Fault detection with alerts that prevent unexpected production stoppages
  • Maintenance interval tracking for timely servicing without production disruption
  • Sound enclosures and vibration isolators reduce operational noise to between 57 and 67 dB
  • User-friendly interface for straightforward daily operation without specialist training

For Kolkata's pharma, food, and electronics facilities where compressed air quality directly affects product integrity, this level of operational control is a practical necessity.

Why frank?

Why Frank Compressors for Oil Free Screw Air Compressors?

Direct Manufacturer Supply

Frank manufactures every oil free screw air compressor in-house and supplies directly across Kolkata with factory-direct pricing.

Full Range from 10 HP to 75 HP

Nine standard models support applications ranging from small processing units to large industrial production facilities.

VSD Technology as Standard

Every Frank oil free screw compressor includes variable speed drive technology for demand-based energy-efficient operation.

Buy Oil Free Screw Air Compressors from Frank Compressors

Tell us your required air volume in CFM, operating pressure in bar, application type, and shift hours. Frank's team will recommend the right oil free screw air compressor model for your Kolkata facility with factory-direct pricing and local service support.

Call Whatsapp
FAQ

FAQs on Oil Free Screw Air Compressors in Kolkata

Because downstream filters are not enough in sensitive production. Pharma plants want compressed air without oil risk from the start itself.

Yes. Even minor oil carryover can affect packaging quality, product safety, and compliance during food processing operation.

Yes. Textile units use them to avoid oil stains, thread damage, and moisture-related defects during continuous production shifts.

Compression happens progressively in two stages, so outlet temperature stays lower and power consumption reduces during operation.

Yes. Laser cutting systems need clean compressed air because oil contamination affects cut finish and damages laser lenses.

Not necessarily. VSD technology adjusts motor speed automatically according to real-time air demand inside the plant.

Yes. Operating noise remains between 57 dB and 67 dB, making them suitable for indoor industrial environments.

Pharma, food processing, healthcare, electronics, textile, printing, and precision manufacturing industries use them regularly.

No. Compression itself happens without oil contact, so there is no downstream oil carryover to remove later.

Air demand in CFM, pressure requirement, production load, and running hours are checked before selecting the right model.

Yes. Installation, testing, commissioning, and startup support are provided across Kolkata and nearby industrial locations.

Yes. Existing air receivers, pipelines, pressure drops, and load conditions are checked before final integration.

Mostly routine inspection, filter replacement, and monitoring of operating parameters. Service intervals remain comparatively lower.

Yes. Genuine spare parts and trained service teams are available across Kolkata and West Bengal for faster response times.
