Dental clinics cannot risk oil contamination or unstable air supply, as compressed air is used directly in procedures involving patient contact. Standard compressors introduce oil traces, moisture, and noise, which affect instrument performance, hygiene standards, and overall treatment quality in clinical environments.
Frank Compressors manufactures oil free dental air compressors with ISO certified quality standards using precision CNC machining and supplies directly to clinics across Kolkata & West Bengal. These piston-based systems provide clean, oil-free air at every stage, are quiet for patient comfort, can be used continuously on a daily basis, and have an oil-free drainage system that makes for clean maintenance and simple disposal.
Kolkata dental clinics perform procedures like implants, crowns, root canals where an air supply cannot fluctuate during treatment. This air flows directly through instruments within the oral cavity of the patient and must be kept oil-free and dry to prevent contamination of the instrument and to enable accurate treatment.
Frank Compressors manufactures and supplies dental air compressors across a range of configurations for direct supply to Kolkata and West Bengal.
Happy Clients
Dealers
Piston compresses air without oil using coated components for dry operation and zero oil content.
Aluminium cylinder head and cooling fan remove heat quickly, keeping temperature stable during long clinic hours.
The receiver tank stores compressed air to maintain steady pressure when multiple instruments run together.
Intake filter removes dust, bacteria, and airborne particles before compression, protecting patient safety.
Clean, dry air flows through piping to power handpieces, scalers, and air syringes at consistent pressure.
| Model | Piston Displacement | Free Air Delivery | Motor Power | Compressor | Tank Capacity LITRES | |||
|---|---|---|---|---|---|---|---|---|
| LPM | cfm | LPM | cfm | HP | Kw | RPM | ||
| Direct Driven | (Maximum Pressure - 7 kg/cm2 102 PSI, Single Stage, 230V / 1 Ph / 50 Hz) | |||||||
| OF - 7.5D | 80 | 2.82 | 45 | 1.58 | 0.75 | 0.54 | 1440 | 30 |
| OF - 10D | 120 | 4.23 | 68 | 2.40 | 1.00 | 0.75 | 1440 | 30 |
| OF - 15D | 205 | 7.23 | 101.9 | 3.6 | 1.50 | 1.10 | 1440 | 50 |
| OF - 30DT | 410 | 14.4 | 203.8 | 7.2 | 3.00 | 2.20 | 1440 | 110 |
Handpieces, drills and three-way syringes operate on clean, dry compressed air to allow for precise operation during exams, fillings and restorations.
Surgical units use compressed air for bone drills and irrigation systems where contamination-free air is critical.
The preparation and irrigation of root canals are performed with air-powered instruments and demand stable clean air over prolonged periods of use.
Treatment with ultrasonic scalers and curettes requires a constant pressure of compressed air.
Compressed air is used for drying and cleaning in bonding, impressions and appliance fitting where oil free air prevents contamination.
Central dental air compressors are needed for multi-chair training setups to deliver clean air in all operatories.
Frank Compressors dental air compressors are designed for clinical staff, not technical operators. The control system is straightforward and requires no specialist knowledge to operate day to day.
Kolkata dental clinics use these simple controls to run their compressed air system reliably across every clinic day without dedicated technical supervision.
Every unit is built on modern CNC machines to tight tolerances, ensuring consistent air quality, reliable instrument performance, and long service life in clinical use.
Frank Compressors has supplied oil-free compressors to 10,000 plus medical and dental customers across India and export markets, reflecting proven reliability.
We produce clean oil-free drainage with no disposal issues, supporting infection control and environmental compliance in clinical facilities.
Tell us your chair count, clinic type, and daily operating hours. Frank's team will recommend the right dental air compressor configuration for your Kolkata practice with factory-direct pricing and local service support.
