Clean, Reliable Compressed Air Solutions for Food Processing
Compressed air is used in compressed air filling, conveying, packaging, sealing, cleaning, blow moulding and other processes in food and beverage plants every day. The lack of moisture, oil contamination or unstable pressure impacts the hygiene, quality and consistency of the products produced within the facility. Frank Compressors produces oil-free compressors, VFD screw compressors, refrigerated air dryers and air receiver tanks for Class 0 contaminant free compressed air supplies for hygienic food processing applications throughout India.
- 20–50% Reduction in compressed air energy consumption
- 15–30% Reduction in moisture-related contamination risks
- 10–25% Improvement in filling and packaging pressure stability
- 15–35% Reduction in compressor cycling during peak demand
- 10–20% Improvement in continuous production airflow stability
- 15–30% Improvement in hygiene compliance across processing environments
Compressed Air Solutions for Food and Beverage Plants
Compressed air is used in compressed air filling, conveying, packaging, sealing, cleaning, blow moulding and other processes in food and beverage plants every day. The lack of moisture, oil contamination or unstable pressure impacts the hygiene, quality and consistency of the products produced within the facility. Frank Compressors produces oil-free compressors, VFD screw compressors, refrigerated air dryers and air receiver tanks for Class 0 contaminant free compressed air supplies for hygienic food processing applications throughout India.
We provide industrial air compressors suitable for different types of manufacturing units, helping businesses maintain consistent production performance with efficient compressed air delivery.Our systems are suitable for continuous-duty industrial applications and varying operational requirements.
Our range includes rotary screw air compressors, VFD screw compressors, oil-free compressors, air dryers, and air receivers for multiple industrial applications.
Years Experience
Happy Clients
Countries Served
Oil-Free Screw Compressors for Food Plants
Frank Compressors's OFS Series delivers Class 0 oil-free compressed air by eliminating oil from the compression process entirely, with zero oil carryover at any stage. Output adjusts from 0% to 100% via variable speed drive, matching actual production demand while reducing power consumption across continuous food processing shifts.
| Technical Feature | Specification Details |
|---|---|
| Power Range | 10 HP to 75 HP / 7.5 kW to 55 kW |
| Working Pressure | 7 to 10 kg/cm² (100 to 145 PSI) |
| Airflow Capacity | 31 CFM to 354 CFM |
| Noise Level | 57 dB to 67 dB(A) |
| Air Purity Standard | Class 0, oil-free and steam-free compressed air |
| Speed Control | Variable speed drive, 0% to 100% output adjustment |
| Oil Carryover | Zero, dry compression with no lubrication at any stage |
Oil-Free Scroll Compressors for Food Units
Frank's scroll compressors use a fixed and orbital scroll mechanism with only two moving parts, producing continuous oil-free airflow below 55 dB(A) with near-zero floor vibration. Their compact footprint and water-cooled rugged cast iron design make them the right fit for dairy units, confectionery lines, and hygiene-sensitive production zones with limited space.
| Technical Feature | Specification Details |
|---|---|
| Power Range | 3 HP to 30 HP / 2.2 kW to 22 kW |
| Working Pressure | 8 to 10 kg/cm² (100 to 145 PSI) |
| Airflow Capacity | 8.5 CFM to 88 CFM |
| Noise Level | Below 55 dB(A), near-zero vibration |
| Scroll Blocks | 1 to 4 scroll blocks depending on model |
| Tank Capacity | 220 L to 270 L (tank-mounted models) |
| Lubrication | 100% oil-free, no oil at any compression stage |
Rotary Screw Compressors for Food Factories
Frank's Mute and Mute HD Series use direct drive technology with a three-stage air-oil separator holding carryover below 3 PPM, delivering stable, pulsation-free air across full production shifts. A microprocessor-based touchscreen controller monitors all operating parameters and maintenance schedules in real time, reducing unplanned downtime on the production floor.
| Technical Feature | Specification Details |
|---|---|
| Power Range | 3 HP to 125 HP / 2.2 kW to 90 kW |
| Working Pressure | 7 to 13 kg/cm² (100 to 188 PSI) |
| Airflow Capacity | 9.5 CFM to 572 CFM |
| Oil Carryover | Less than 3 PPM via 3-stage air-oil separator |
| Drive Type | Direct drive, no belt system |
| Control System | Microprocessor-based with touchscreen display |
| Cooling System | Oversized air and oil cooler with large cooling fan |
VFD Screw Compressors for Beverage Plants
Frank's VFD compressors operate in a constant pressure variable mode, continuously adjusting motor RPM via a branded world-renowned inverter to match real-time air consumption across bottling, dairy, and bakery lines. Over a 3-year operating period, the cumulative energy savings from VFD operation typically exceed the original equipment capital cost.
| Technical Feature | Specification Details |
|---|---|
| Power Range | 15 HP to 125 HP / 11 kW to 90 kW |
| Working Pressure | 7 to 13 kg/cm² (100 to 188 PSI) |
| Airflow Capacity | 71 CFM to 572 CFM |
| Noise Level | 72 to 74 dB(A) |
| Speed Control | Constant pressure variable operating mode via inverter |
| Oil Carryover | Less than 3 PPM |
| Inverter Source | Branded inverter from a world-renowned manufacturer |
Permanent Magnet Compressors for Food Units
Frank's IE4/IE5 permanent magnet motor retains synchronous torque and peak energy efficiency at all load levels, including partial loads where standard induction motors waste the most power. This makes them the most cost-efficient choice for food processing plants running compressed air systems continuously across multiple production shifts every day.
| Technical Feature | Specification Details |
|---|---|
| Power Range | 10 HP to 75 HP / 7.5 kW to 55 kW |
| Working Pressure | 7 to 13 kg/cm² (100 to 188 PSI) |
| Airflow Capacity | 40 CFM to 355 CFM |
| Motor Grade | IE4/IE5 Permanent Magnet Motor |
| Energy Savings | 3-year energy savings exceeds equipment capital cost |
| Operation Mode | Synchronous torque at all load levels including partial load |
| Lubrication | Oil-injected with less than 3 PPM carryover |
Refrigerated Air Dryers for Food Processing
Frank's refrigerated air dryers cool compressed air to condense and drain moisture before it enters the distribution network, maintaining a stable dew point across continuous operation. This directly prevents mold growth on food-contact surfaces, internal pipeline corrosion, and reduced shelf life of packaged products caused by wet compressed air.
| Technical Feature | Specification Details |
|---|---|
| Function | Removes water vapour from compressed air supply |
| Dew Point Control | Stable dew point maintained across continuous operation |
| Moisture Risk Eliminated | Mould, bacterial growth, pipeline corrosion |
| Compatibility | All Frank compressor models |
| Suitable Environments | Humid, tropical, and high-moisture industrial conditions |
| Installation | Skid-mounted, minimal labour required for setup |
Vacuum Pumps for Food and Beverage Industry
Frank supplies piston vacuum pumps for packaging evacuation, degassing, fermentation, and milk processing, and rotary vane vacuum pumps for vacuum drying, oil extraction, and vacuum-sealed container operations. Both types are available in multiple capacities, from low vacuum to high vacuum, covering the full range of food and beverage process requirements.
| Technical Feature | Specification Details |
|---|---|
| Types Available | Piston vacuum pumps and rotary vane vacuum pumps |
| Piston Pump Applications | Packaging evacuation, degassing, fermentation, milk processing, drying |
| Rotary Vane Applications | Vacuum drying, vacuum extraction, vacuum packaging, vacuum coating |
| Vacuum Range | Low vacuum to high vacuum depending on model |
| Sizes Available | Multiple capacities to match different facility scales |
| Air Quality | Clean, contaminant-free vacuum for food-contact operations |
Air Receivers for Food Production Facilities
Frank's ARV Series receivers store compressed, clean, dried air and release it instantly during simultaneous demand peaks from filling heads, packaging machines, and conveyor actuators to prevent pressure drops. Available from 500 L to 10,000 L at structural pressure ratings up to 45 kg/cm2, they are built and certified to ISO 9001:2015 standards.
| Technical Feature | Specification Details |
|---|---|
| Storage Capacity | 500 Litres to 10,000 Litres |
| Working Pressure | 7 to 45 kg/cm² (100 to 650 PSI structural ratings) |
| Certification | ISO 9001:2015 certified pressure vessels |
| Function | Pressure buffer for simultaneous demand spikes |
| Applications | Blow-off, cleaning, filling, packaging, sorting |
| Build Standard | Heavy-gauge pressure vessels with safety compliance |
Industries We Serve in Food and Beverage
Dairy Processing Plants
In dairy, oil-free scroll, screw compressors are applied in milk processing and pasteurisation lines and on packaging lines to provide clean, dry air and minimise contamination issues.
Beverage Bottling Units
VFD screw compressors adapt to the demand of the bottling line, matching its speed during periods of low production and at shift change in order to avoid wasting power.
Breweries & Wineries
The compressed air facilitates oxygen transfer in wine and beer fermentations while the oil-free air minimizes flavour contamination in the process interior.
Bakeries & Confectioneries
Oil-free scroll compressors below 55 dB(A) are ideal for cream filling, ingredient mixing and packaging in production areas without adding noise.
Mineral Water Plants
Continuous mineral water production operations use compressed air for ozone sterilisation, bottle filling, degassing and pneumatic sealing.
Fruit & Vegetable Processing
Lower contact with the product, peeling, cutting and pneumatic conveying are done with compressed air and reduced in fruit and vegetable processing lines.
Edible Oil Processing
Rotary vane vacuum pumps remove oils from seeds, nuts, or olives under vacuum that helps retain oil purity and quality during the extraction process.
Spice & Condiment Manufacturing
During the packaging operation, dry, clean compressed air carries spices and powder without clumping, contaminating or losing the product.
Meat & Seafood Processing
Vacuum pumps produce low oxygen packaging conditions for meat and seafood products to help control bacterial growth and prolong storage time.
Frozen Food Manufacturers
Cold, dry compressed air can freeze and chill foods more quickly throughout processing lines without compromising food texture and quality.
Snacks & Packaged Food Units
VFD screw compressors help prevent energy waste during shift changes and meet machine cycle demands on high speed packaging lines.
Tea & Coffee Processing
Oil-free compressed air is used to sort, blend, vacuum seal and nitrogen flush in tea and coffee processing plants.
Pasta & Noodle Manufacturing
Compressed air conveys dry pasta and noodle products through pipelines and operates pneumatic sealing and packaging systems across the line.
Sugar & Confectionery Plants
Clean, dry compressed air operates filling heads, coating drums, and packaging systems where air quality directly affects product purity.
Ready-to-Eat Food Plants
Compressed air drives automated filling, portioning, sealing, and labelling systems where hygiene, speed, and production consistency all matter.
Seafood Cold Storage Facilities
Refrigerated air dryers and vacuum systems maintain controlled moisture and vacuum conditions inside seafood storage and processing environments.
Baby Food Manufacturing Units
Baby food plants require strict Class 0 oil-free compressed air across both contact and non-contact production applications.
Pharmaceutical-Grade Nutraceutical Plants
Nutraceutical manufacturers use oil-free compressed air for capsule filling, powder conveying, tablet coating, and GMP cleanroom pressurisation.
Flour & Grain Milling Units
Compressed air conveys flour and grain through pipelines, cleans milling equipment, and operates pneumatic gates across automated milling systems.
Juice & Pulp Processing Plants
Oil-free compressed air supports hygienic filling, conveying, pasteurisation, and aseptic packaging where even trace oil contamination becomes a safety risk.
Why Food & Beverage Leaders Partner With Frank Compressors?
Certified Class 0 Purity
Our dry compression chambers eliminate oil carryover to guarantee complete compliance and zero batch contamination during food-contact packaging.
Audited Production Verification
We enforce strict Kaizen protocols and provide full-load test logs with every compressor to ensure immediate operational efficiency.
Rapid Compliance Logistics
More than ten regional service hubs maintain deep inventories of food-safe consumables to secure uninterrupted facility runtime nationwide.
Sizing Your Food Plant Compressed Air System
Compressed air system sizing should match actual production demand, operating cycles, and pressure requirements across food processing and packaging operations.
Total Air Demand (CFM)
Calculate the combined airflow requirement of machines operating simultaneously during peak production.
Duty Cycle Adjustment
Apply operating load factors based on actual runtime conditions and production cycles.
System Safety Margin
Add a 20–30% buffer for leakage, expansion, and system pressure losses.
Pressure Requirement Selection
Set compressor pressure based on the highest-pressure application, typically 7–10 kg/cm² in food processing operations.
Get a System Quote for Your Food Processing Plant
Share your airflow demand, pressure range, and production requirements with the Frank Compressors team for a compressed air system recommendation tailored to your food processing and packaging operations.
